| Recommended Supply Voltage | 5 – 8 V DC |
| Supply Current | 30 mA |
| Weight | 20 g |
| Protection Rating | IP 66 |
| Size | 36.6 x 26.0 x 12.3 mm (l x w x h) |
Features reverse polarity protection and over-temperature protection (125°C).
| Supply Voltage | Red |
| Ground | Black |
| CAN+ | Blue |
| CAN- | White |
| Standard | CAN2.0A (11 bit identifier) ISO-11898 |
| Bit Rate | 1 Mbit/s |
| Byte Order | Big-Endian / Motorola |
| Scale | 0.1°C/bit |
| Offset | -100°C |
| Base CAN IDs | Front Left Sensor: 0x4C4Front Right Sensor: 0x4C9Rear Left Sensor: 0x4CERear Right Sensor: 0x4D3 |
