Video VBOX Lite PIN OUTS

Updated on Mar 13, 2026

Connector 1 - Power #

PIN	I/O	Function
1	I	Power+(9 to 15V)
2	I	Ground (0V)

Connectors 2 / 3 - Cameras 1 and 2 #

PIN	I/O	Function
5	I/O	Ground
7	I	Video Input
3	O	Camera Power (8 - 18 V)

Connector 4 - CAN #

PIN	I/O	Function
1	O	Digital Output
2	I/O	CAN High
3	I/O	CAN Low
5	I/O	Ground
6	I	Digital Input
8	O	Power

Connector 5 – AUX #

PIN	I/O	Function
1	I	RS232 Tx
3	O	RS232 Rx
5	I/O	Ground
6	O	Video Out
8	I	Power +12V(1A Max)

Connector 6 - USB #

PIN	I/O	Function
1	I	USB - 5V

Connector 7 – GPS Antenna #

PIN	I/O	Function
1	I	Signal
2	I	Ground
